GEN II 40/60 ENHANCEMENT HIGHLIGHTS:
New 2.4L PSI Dual Fuel Engine – Smoother and quieter than previous 3.0L engine
New 2-Speed Drive Hubs – Improved speed control with smoother driving and better acceleration with auto shift feature
New Creep Mode – Hydraulic functions are slowed down for precise movement / control at high RPM
Enhanced Capacity Calculator – Senses how many counterweights are loaded and how far the counterweight is extended to provide real time load capacities for safer picks and increased job efficiency. ALSO, provides floor pressures & axle weights.
Grade Holding – This feature has two facets; the parking brake once applied now remains engaged until the parking brake is not only released, but also the operator pedal is actuated. The second facet of this feature is an automatic brake engagement if the drive motors change direction while the operator is not applying the accelerator, limiting rollback while on an incline.
Overload Warning – Will produce a visual & audible warning indicting that the unit has been overloaded. The unit will continue to operate normally and the alarm will turn off once the unit is back within its rated capacity.
CAPACITIES
Forks: 41,400 LBS @ 36″ LC (RETRACTED) / 61,600 LBS @ 36″ LC (EXTENDED)
35,200 LBS @ 48″ LC (RETRACTED) / 52,300 LBS @ 48″ LC (EXTENDED)
Boom: 40,000 LBS @ 24″ LC (RETRACTED) / 59,400 LBS @ 24″ LC (EXTENDED)
33,700 LBS @ 36″ LC (RETRACTED) / 50,200 LBS @ 36″ LC (EXTENDED)
